SBD-101 | Haulotte Compact 10DX

Bild 0 einer Mietmaschine vom Typ SBD-101 | Haulotte Compact 10DXBild 1 einer Mietmaschine vom Typ SBD-101 | Haulotte Compact 10DXBild 2 einer Mietmaschine vom Typ SBD-101 | Haulotte Compact 10DX
Vorschaubild 0 einer Mietmaschine vom Typ SBD-101 | Haulotte Compact 10DXVorschaubild 1 einer Mietmaschine vom Typ SBD-101 | Haulotte Compact 10DXVorschaubild 2 einer Mietmaschine vom Typ SBD-101 | Haulotte Compact 10DX

Technical data

Below you will find all product details.

Working height
10,15 m
Lifting capacity
565 kg
Platform size
(3,70 m) x 2,45 m x 1,45 m
Platform height
8,15 m
Platform length extended
3,70 m
Dimensions
3,17 m x 1,78 m x 1,59 m
Weight
3.520 kg
Make
Haulotte
Model
Compact 10DX
Drive unit
Diesel
Article designation
SB-101D

SBD-101 | Haulotte Compact 10DX – scissor lift

Diesel scissor lift 10 m Haulotte Compact 10DX

This Haulotte scissor lift is designed for use on rough terrain. It also stands out with its high load capacity. The maximum working height is 10.15 metres. The Compact 10DX lift has a maximum load capacity of 565 kg. This maximum load capacity should not be exceeded, as otherwise unintended damage to the machine may occur.

Hire the Haulotte scissor lift with around 10 metres

The aerial work platform has a four-wheel drive system for excellent performance on rough terrain and poor ground. The scissor lift also has a ground clearance of 28 cm. In addition, the work platform has a small turning radius for greater mobility. The Compact 10DX lift also features a 3.6 m2 platform, so the lift can be used by several people at the same time. An integrated diagnostic system for fast troubleshooting is also on board. This supports productive work. Overall, this work platform has a user-friendly system. Are you interested in the Compact 10DX lift? We will be happy to discuss the job with you and prepare an individual quote. Put this excellent Haulotte lift to work on your own site as well.

Key technical data

  • Working height: 10.15 m
  • Load capacity: 565 kg
  • Width: 1.78 m
  • Height: 2.44 m
  • Weight: 3,520 kg

Check availability and request a quote now.
